2 post flour plate 4 click here to download file in pdf
4000kgs hydraulic two post lift with manul release
CE Post Lift Specification
1.Driven by double hydraulic cylinders, steel wire chain-type elevating system
2.Oil cylinder parts made by automatic high rotation speed CNC lathe ensure the excellent finish and concentration.
3. Automatic arm restraints, lifting arm automatically engages when lift is raised, and disengaged when lift lowered to the ground.
4.Single side safety control, arm locks with tooth type ratchet, mufti-safety device, more reliable.
5. 3-stage Screw-up pads suitable for low chassis vehicle as well as SUVs, makes easy and quick service.
6.Door opening protection rubber as standard.
7.The overall design is suitable for tire tear open outfit, chassis maintenance, oil changes and maintenance, engineering vehicles such as regular vehicle maintenance; (suitable for conventional garage and service station to purchase)
8. Optional imported pumping device, optional 3 -stage lower telescopic arm.
9. Pass CE 6000KG static test, 4.6Tdynamic test.
Post Lift Details:
Post Lift Details:
| Model | SHL-2-240W |
| Lift Capacity | 4000KG |
| Lifting height | 1835mm |
| Min. Height | 85mm |
| Lifting Time | 50s |
| Drop time(appro.) | 30s |
| Power of motor | 2.2KW |
| Power supply | 220V/380V |
| Inner Width | 2860mm |
| Total Width | 3420mm |
| Overall height | 2820mm |
