ر.ع.1,350.00
1 Max hose ID: φ 6~ 69mm (maximum 2.5 inch, min 2 min)
2 Theoretical Crimping Force: 600 Ton
3 Rated voltage: three-phase AC380V or single-phase AC220V
4 Mold opening and closing cycle: 8s
5 Opening without dies: 136mm
6 Motor Size: 3KW
7 Random supporting mold: 13 set (14, 16, 20, 22, 26, 30, 34, 38, 46, 51, 54, 64, 69)
8 Electrical Requirement: 380V/50Hz-3Ph ~ 220V/50Hz-1Ph
9 Dimensions: 870(L)x680(W)x1380 (H)mm
10 79 litres 46# hydraulic oil.
11 Weight: 330KG
1 Max hose ID: φ 6~ 69mm (maximum 2.5 inch, min 2 min)
2 Theoretical Crimping Force: 600 Ton
3 Rated voltage: three-phase AC380V or single-phase AC220V
4 Mold opening and closing cycle: 8s
5 Opening without dies: 136mm
6 Motor Size: 3KW
7 Random supporting mold: 13 set (14, 16, 20, 22, 26, 30, 34, 38, 46, 51, 54, 64, 69)
8 Electrical Requirement: 380V/50Hz-3Ph ~ 220V/50Hz-1Ph
9 Dimensions: 870(L)x680(W)x1380 (H)mm
10 79 litres 46# hydraulic oil.
11 Weight: 330KG
