Line Boring Machine — Cylinder Heads & Blocks
ر.ع.3,965.65
-
Line Boring Machine is built for precision re-boring of main bearing housings in cylinder heads and engine blocks. The carriage uses a guideway system for accurate alignment; spindle feed is stepless for optimal surface finish. With centering fixtures, micro-adjust boring tool, gauges, and sleeves, the LB1000 delivers repeatable accuracy for automotive service and engine rebuild shops.
-
ring range: φ24–φ110 mm
-
Max. distance (between parallel & shaft center): 450 mm
-
Max. length of workpiece: 1000 mm
-
Max. movement of main shaft: 100 mm
-
Spindle speed: 580 / 373 r/min
-
Feeding of boring shaft: Stepless
-
Main motor power: 0.75 kW / 0.55 kW
-
Overall dimensions (L×W×H): 1850×600×1375 mm
-
Packing size (L×W×H): 1980×750×1700 mm
-
Weight: ≈ 600 kg
الملحقات القياسية (Standard Accessories)
-
Boring bar
-
Centering sleeve(s)
-
Boring tool sleeve
-
Micro adjuster for boring tool
-
Boring cutter
-
Boring sleeve set
-
Increase tool plate (support)0
-
Align gauge
-
Centering gauge
Only 2 left in stock
-
Line Boring Machine is built for precision re-boring of main bearing housings in cylinder heads and engine blocks. The carriage uses a guideway system for accurate alignment; spindle feed is stepless for optimal surface finish. With centering fixtures, micro-adjust boring tool, gauges, and sleeves, the LB1000 delivers repeatable accuracy for automotive service and engine rebuild shops.
-
ring range: φ24–φ110 mm
-
Max. distance (between parallel & shaft center): 450 mm
-
Max. length of workpiece: 1000 mm
-
Max. movement of main shaft: 100 mm
-
Spindle speed: 580 / 373 r/min
-
Feeding of boring shaft: Stepless
-
Main motor power: 0.75 kW / 0.55 kW
-
Overall dimensions (L×W×H): 1850×600×1375 mm
-
Packing size (L×W×H): 1980×750×1700 mm
-
Weight: ≈ 600 kg
الملحقات القياسية (Standard Accessories)
-
Boring bar
-
Centering sleeve(s)
-
Boring tool sleeve
-
Micro adjuster for boring tool
-
Boring cutter
-
Boring sleeve set
-
Increase tool plate (support)0
-
Align gauge
-
Centering gauge
