Description
※ Automatic mains voltage monitoring.
※ Overheating protection.
※ Designed for dent pulling of different kinds of car steels such as conventional steel and stainless steel.
※ With HUA curved silicon steel sheet and energy efficient main transformer.
※ With DELIXI, OMRON and PANASONIC high quality relay.
※ High precision time adjustment system.
※ Equipped with switchable spot gun and multifunctional puller.
※ Uniquely designed gun cable support arm allows flexible movement with 360°rotation.
※ Complete with air filter and pressure regulator.
※ Stepless current and time regulation.
※ Single-sided and double-sided welding.
※ Digital graphic LCD display.
※ 10 preset weld programs.
※ 60 memory functions.
※ Electrodes of C-type gun can be step-by-step opened and quadratic rapid closed (X-type gun is available as an option).
※ Variety of welding procedures are available such as shrinking, washer, direct-pulling, spot welding, flattening, waveform wire,
stud welding, OT washer and triangle washer.
Technical Data
| Input voltage: Input power: Input current: Max welding current: One-side welding thickness: Two-side welding thickness: Air supply pressure: Operation way: Welding time range: Dimensions: Weight: |
AC380V 50/60Hz 30KVA 50A 9900A 1.0+1.5mm 2.5+2.5mm 4-8kg Electronic timer continuously 0-99s 700x530x1800mm 138kg |
Due to the continuous innovation and upgrade, our products’ features may be updated.
Standard X-type Gun
Quick Puller
Control Panel
X-type Gun Detail
Pictures are for reference only, please subject to our available products.
