Electronic tram
gauge for vehicle
measuring

EzCalipre3D is an advanced measuring
device for exact verification of vehicle
chassis and body condition and for damage
documentation, developed by Autorobot
Finland Oy. EzCalipre3D is easily portable
and movable, it can be used for 2D or 3D
measuring in all kinds of surroundings, and
therefore it opens up whole new scopes for
vehicle estimation.
Electronic tram
gauge for vehicle
measuring
Page

Applicable everywhere
System calibration and electronic measuring can
be done on the body shop yard or on a post lift
when estimating the vehicle’s repair cost, or during
straightening work when the car is mounted in a frame
bench of any kind, or when the car has been brought in
an inspector’s office to be certified for roadworthiness
for example.
Modern data transfer
Data on vehicle’s present condition, which is provided
by EzCalipre’s length sensor and inclinometer for
height, gets transmitted in the PC measuring software
with wireless WLAN connection (Wireless Local Area
Network). Immediate, direct data transfer totally
eliminates mistakes with typing etc. Measuring results
can be viewed immediately both on EzCalipre3D
display and on PC screen.

Damage analysis
Measuring with EzCalipre3D makes vehicle
straightening work quicker and ensures the quality
of your work. EzCalipre’s technique is supported by
Autorobot’s own, very comprehensive vehicle data
files (approximately 60 reference points per vehicle).
EzCalipre3D provides a quick report on side damage,
showing by how many millimeters the B pillar has bent
in (the first picture) for example, and if the crash has
shortened the middle section of the body (the second
picture). This information helps to produce a realistic
cost estimate and repair schedule. In these pictures the
measured values are saved in a portable computer.
Areas of use
EzCalipre3D is suitable for measuring passenger
vehicles, cross country vehicles and vans, and its’ most
essential purpose is to serve body shop diagnostics and
structural vehicle repair. Wireless and easily portable
with the carry case, it is easy to move around. Just like
your laptop, EzCalipre3D with Li-Ion battery makes it a
mobile solution which adapts to the moving work of
insurance company inspectors, for example.
Patented.
Wireless data transfer
EzCalipre3D central processing unit (CPU) reads the
exact locations of the vehicle points with the help of
in-built sensors for length and vertical inclination.
Measuring points can be selected in the display of the
CPU, and saved in the computer database. Chassis and/
or body points that were saved during the measuring
session can be printed out on separate Before Repair
or After Repair reports, or both. Autorobot EzCalipre3D
tram gauge uses wireless WLAN technique and
therefore it can be used with nearly all kinds of
computers.

•

  Line Boring Machine is built for precision re-boring of main bearing housings in cylinder heads and engine blocks. The carriage uses a guideway system for accurate alignment; spindle feed is stepless for optimal surface finish. With centering fixtures, micro-adjust boring tool, gauges, and sleeves, the LB1000 delivers repeatable accuracy for automotive service and engine rebuild shops.



•

• ring range: φ24–φ110 mm

• Max. distance (between parallel & shaft center): 450 mm

• Max. length of workpiece: 1000 mm

• Max. movement of main shaft: 100 mm

• Spindle speed: 580 / 373 r/min

• Feeding of boring shaft: Stepless

• Main motor power: 0.75 kW / 0.55 kW

• Overall dimensions (L×W×H): 1850×600×1375 mm

• Packing size (L×W×H): 1980×750×1700 mm

• Weight: ≈ 600 kg

الملحقات القياسية (Standard Accessories)

• Boring bar

• Centering sleeve(s)

• Boring tool sleeve

• Micro adjuster for boring tool

• Boring cutter

• Boring sleeve set

• Increase tool plate (support)0

• Align gauge

• Centering gauge

Electronic measuring gauge with wireless Wi-Fi connection

Autorobot EzCalipreLT is suitable for exact verification of vehicle chassis and body condition and documenting the quality of repairs. Mobile measuring system performs measuring tasks during the repair process quickly and cost-effectively.

echnical Specifications

• Measurement Accuracy: ±0.5 mm
• Digital Display Resolution: 1 mm
• Usability: Can be used with Autorobot’s measuring software or independently
• Length: 1.2 m
• Extension Pieces: First extension 0.7 m, second extension 0.9 m
• Measuring Range: Minimum 235 mm, maximum 2800 mm
• Battery: Rechargeable Li-Ion battery
• Operating Time: Approximately 20 hours
• Indicators: Wireless connection and battery level indicators

System Requirements

• Processor: PC with at least a 2 GHz processor (recommendation: multi-core processor)
• Operating System: Microsoft Windows 10 or 11
• Display Resolution: Recommended 1920×1080 (minimum 1366×768)
• RAM: 4 GB (minimum 2 GB)
• Hard Drive Space: 4 GB free space (minimum 2 GB)
• USB Ports: 2× free USB2/USB3 ports for WLAN adapter / USB stick
• Printer: Inkjet or laser printer (color printer recommended for printing measurement point images)

JP-LC-P200 Laser Cleaning System

Overview

The JP-LC-P200 is a next-generation laser surface cleaning system designed for efficient, precise, and eco-friendly removal of contaminants, rust, paint, and oxides from metal and non-metal surfaces. With advanced control software, ergonomic design, and maintenance-free operation, it delivers superior results in industrial cleaning and surface preparation.

Key Features

• Non-Contact Cleaning: Removes rust, coatings, and contaminants without damaging the substrate.

• Chemical-Free Operation: No solvents or consumables—environmentally friendly and safe.

• High Precision: Adjustable laser parameters for selective cleaning of targeted areas.

• Dual Operation Modes: Can be operated manually or integrated into automated robotic systems.

• User-Friendly Interface: Equipped with a 7-inch touch screen (optional 4.3-inch), intuitive controls, and multilingual support.

• Ergonomic and Lightweight Design: The cleaning head weighs less than 1.25 kg, ensuring comfortable long-term use.

• Advanced Cooling and Dust Protection: Sealed optical path and dust-blowing air curtain protect optics for long service life.

• Multiple Cleaning Patterns: Choose from 9 cleaning modes, including linear, rectangular, circular, sine, helix, and ring—perfect for various industrial applications.

Technical Specifications

Applications

• Rust and oxide removal

• Paint and coating removal

• Pre-weld and post-weld cleaning for aluminum alloys

• Oil, grease, and surface contaminant removal

• Restoration of historical metal surfaces

• Rubber mold, rail, marine, and automotive component cleaning

Package Includes

• JP-LC-P200 Laser Cleaning Head

• JP-FLCS Control Box (with galvanometer system)

• Touch Screen Interface

• Built-in Process Database (50 preset process slots)

• Standard F210 Field Lens (optional: 160 mm – 420 mm)

• Protective Lenses (x2)

آلة خرط أقراص ودرام الفرامل - LXF 650 ( صناعة كورية
المواصفات الفنية :
•
نطاق العمل : سماكة القرص 90 ملم / القطر 450 مل م
قطر الدرام 450 ملم / العمق 120 ملم
•
عدد اللفا ت (RPM): من 1 إلى 120 دورة بالدقيقة )نظام نقل متغير السرعة عبر العاكس(
•
الموتور الرئيسي : 220/380 فولت، 50 / 60 هرتز، 3 فاز، قدرة 1 حصان
•
الدقة : 0.05 ملم ) 0.001969 إنش (
•
الطاقة الكهربائية المطلوبة : 100/220 فولت – 50 / 60 هرتز
•
الاهتزاز (Run-out): الحد الأقصى 0.003 ملم ) 0.000079 إنش (
•
ضبط السرعة : عبر عاكس مدمج وشاشة رقمي ة
•
نظام الحركة : قيادة بخط مستقيم (Linear Drive)
•
العمود : قطعة واحدة مدمجة عالية المتانة
•
نظام الانزلاق الجانبي : مسار على شكل V لضمان الثبات والدقة
•
القطع والسنفرة :
o
طريقة السنفرة: ثابتة
o
نوع السنفرة: قرص قابل للفك
o
محولات (Con-adapter): أحجام 88 / 105 / 128 مم ) 4 قطع مع الطقم(
•
الإضاءة والحماي ة : إضاءة LED عدد 60 / غطاء أمان أكريليك شفاف
•
الأبعاد : العرض 860 الطول × مم 540 الارتفاع × مم 1500 مم
•
الوزن الكلي : 240 كجم
•
اللون : أحمر )لون الجسم الأساسي(
المميزات البارزة :
•
شاشة رقمية لعرض عدد اللفات بدقة
•
مايكرومتر لضبط عمق القطع يمين ويسار
•
نظام تحكم يدوي وآلي بأزرار سهل ة
•
غطاء واقي شفاف لحماية الفني من الشرر وبقايا المعادن
•
هيكل صلب ومتين مصمم للاستخدام الصناعي المكثف
•
مساحة تخزين جانبية للأدوات والمحولات
